Premium Woven Filter Cloth for Every Industrial Filtration Process
Skytech Ultrafab Woven Filter Cloth is manufactured on precision looms using polypropylene, polyester, nylon, cotton, PTFE, and stainless steel yarns in plain, twill, and satin weave architectures. Supplied by the metre or fabricated to finished filter shapes, our cloth delivers precisely controlled air permeability, tensile strength, and particle retention for filter presses, centrifuges, belt presses, and vacuum drum filters across all industries.
What Is Woven Filter Cloth?
Woven Filter Cloth is a fabric produced by interlacing warp and weft yarns on a loom in a repeating geometric pattern. The choice of yarn material, yarn count, weave pattern, and finishing treatments determines the filtration characteristics — micron retention, flow rate, cake release, and chemical compatibility — of the finished cloth.
Features and Benefits
- Precision-Controlled Porosity: Warp and weft yarn counts selected to achieve the exact micron retention specified by the filtration process requirement
- Wide Material Range: PP, PES, nylon, cotton, PTFE, and stainless steel — covering pH 0–14 and temperatures from cryogenic to 260°C
- Multiple Weave Patterns: Plain weave for maximum retention, twill for balance of flow and retention, satin for maximum flow and superior cake release
- Surface Treatments: Heat-setting, singeing, and calendering applied to tune the cloth surface for the target application
- Supplied as Fabric or Fabricated Shapes: Available by the metre roll or cut and fabricated into filter press cloths, centrifuge bags, belt press belts, and drum filter sleeves
- Dimensional Accuracy: Fabric width held to ±2 mm tolerance; shrinkage minimised by heat-setting to ensure finished filter shapes fit precisely
Technical Specifications
| Parameter | Details |
|---|---|
| Available Materials | PP, Polyester, Nylon, Cotton, PTFE, SS Wire |
| Weave Patterns | Plain, 2/1 Twill, 2/2 Twill, 5H Satin, 8H Satin |
| Micron Rating | 1 – 500 µm |
| Fabric Width | Up to 2500 mm |
| Yarn Count | Monofilament, Multifilament, Spun (application-specific) |
| Max Temperature | PP: 90°C | PES: 135°C | Nylon: 120°C | PTFE: 260°C |
| pH Range | PP/PTFE: 0–14 | PES/Nylon: 3–13 |
| Supply Form | Roll (metre goods) or fabricated filter shapes |
Applications
- Filter Press Dewatering: Chemical, pharmaceutical, mineral, sugar, and wastewater filter press cloth — the largest single application for woven filter cloth
- Centrifuge Filtration: Basket centrifuge bags for pharmaceutical API, sugar, chemical salt, and textile dyeing applications
- Belt Filter Press: Continuous belts for municipal wastewater sludge, mining concentrate, and paper pulp dewatering
- Rotary Vacuum Drum: Continuous cloth sleeves for vacuum drum filtration in mining, chemicals, and paper pulp
- Candle Filters: Precision-woven candle filter sleeves for edible oil, beverage, and pharmaceutical polishing
Why Choose Skytech Ultrafab for Woven Filter Cloth?
- In-House Weaving: Full control over every production parameter from yarn selection to finished cloth specification — no quality compromises
- Application Engineering: Expert cloth specification service — material, weave, and finishing selected to optimise filtration performance for your specific process
- Custom Fabrication: In-house cutting, sewing, and heat-sealing to produce any filter shape to drawing dimensions
- Quality Certification: Test certificates for air permeability, tensile strength, weight, and thickness issued with every order
- Export Experience: Woven filter cloth exported to customers in the Middle East, Africa, South-East Asia, and Europe
